Pogo Pin Connectors Pogo Pins (Spring Loaded Pins) are used in almost every kind of electronic device today. Their high durability, tolerance and versatile application make them a preferred connector for intelligent electronic designs. Standard Connector: INEXPENSIVE, COMPATIBLE, HIGH QUALITY Single Pogo Pins Single Pogo Pins in great variety and form. Easily customizable. […]
Burn In Test Solutions The Burn-In test will expose the DUT (device under test) to harsh conditions: 150°C; relative humidity (RH): 85 rh; current rating: 1A continuous for 1000 hrs. In order to withstand conditions like that, C.C.P. modifies the plating material and core material. C.C.P. splits the socket into two parts: The standard part […]
Network Cable Presentation SFP 25Gbps: 25G Ethernet DAC Cable Ultra-thin DAC Cables with wire gauges between 26-32AWG and up to 5m lengths. Compliant with SFF8431 & SFF8432 cable. QSFP 100Gbps: 100Gbps DAC Network Cable Ultra-Fast 100Gbps QSFP Cables with up to 5m lengths. Apply on data center and server for signal transmission stability […]
Some of our Range of Products Single Female Pins: Over 3,000 DESIGNS Non Standard Connectors: Over 3,000 DESIGNS Wide variety of female landing pad connectors. Magnetic Connectors: 32 DESIGNS We offer customized and standard magnetic connectors with different magnetic forces. Ball Point Connectors: 24 DESIGNS Ball Point connectors are ideal to contact moving targets without […]
Chip size socket connects LPDDR5 to system PCB with minimal signal loss. Supported device size is 14x14mm, 21×21 array, 0.65mm pitch BGA 441. Once the socket is soldered down to PCB, device can be simply plugged into it. This Grypper socket has excellent electrical performance of – 1dB insertion loss greater than 25.0 GHz. Force […]
Image Sensor Sockets: A Key Factor in Camera Design The proliferation of valuable high-resolution, high-speed, and 3D image sensors makes the use of sockets an increasingly important factor in camera development. Camera makers — and, therefore, image sensor makers — today are under greater pressure than ever to offer new models that provide higher resolution […]
The SM-BGA socket is constructed with high performance (> 40GHz bandwidth) and low inductance elastomer contactor. The temperature range is -55 °C to +150 °C. The pin self-inductance is 0.21 nH. Capacitance to ground is 0.15 pF. Current capacity is 4 amps per pin.
Elastomer used in the socket, as a contactor between the IC package and the circuit board, is a low resistance (less than 0.05ohms) connector. The elastomer consists of a fine pitch matrix of gold plated wires in a soft insulating sheet of silicone rubber. The sockets have a precision design, which guides the IC to […]
We have developed the 2.0 mm pitch, small-size, waterproof connector ‘FWS Series (relay type). The ‘FWS Series’ is our 2nd waterproof connector following the ‘FW Series.’ While being compact its protection rating against the ingress of foreign matter into the electrical enclosure satisfies IP67, which is dust tight and has excellent waterproof performance. The most […]
