Chip size socket connects LPDDR5 to system PCB with minimal signal loss. Supported device size is 14x14mm, 21×21 array, 0.65mm pitch BGA 441. Once the socket is soldered down to PCB, device can be simply plugged into it. This Grypper socket has excellent electrical performance of – 1dB insertion loss greater than 25.0 GHz. Force […]
Image Sensor Sockets: A Key Factor in Camera Design The proliferation of valuable high-resolution, high-speed, and 3D image sensors makes the use of sockets an increasingly important factor in camera development. Camera makers — and, therefore, image sensor makers — today are under greater pressure than ever to offer new models that provide higher resolution […]
The SM-BGA socket is constructed with high performance (> 40GHz bandwidth) and low inductance elastomer contactor. The temperature range is -55 °C to +150 °C. The pin self-inductance is 0.21 nH. Capacitance to ground is 0.15 pF. Current capacity is 4 amps per pin.
Elastomer used in the socket, as a contactor between the IC package and the circuit board, is a low resistance (less than 0.05ohms) connector. The elastomer consists of a fine pitch matrix of gold plated wires in a soft insulating sheet of silicone rubber. The sockets have a precision design, which guides the IC to […]
We offer many adapters for converting IC packaging and device pin outs, solving many IC availability and performance issues. We also offer fix adapters to solve layout problems and some known chip deficiencies. Custom, quick turn solutions are our specialty.
Image Sensor Sockets for Luxima Technology Only Available From Andon Electronics Corporation Featuring Andon’s Unique Senstac Contact
Overview Company Overview – Founded 1986 – 100,000 Sockets built – 1M+ adapters built – High Performance Adapters and Sockets – Many Custom Designs & Turn-Key Solutions – Engineering – Electrical and Mechanical – ISO9001:2015 Registration – Customers – Engineering and OEM Capabilities Overview – Simulation QFIN for heat sink design Microwave Studio for electrical […]
Socket your QFP172 using Extreme Temperature Socket with Superior Electrical Performance Ironwood Electronics recently introduced a new socket addressing high performance requirements for Burn-in and Test applications – SBT-QFE-3035. The contactor is a stamped spring pin with 14 gram actuation force per ball and cycle life of 125,000 insertions. The self inductance of the contactor […]
Socket your Flat No Lead package using elastomer socket with superior electrical performance Ironwood Electronics has recently introduced a new high performance elastomer socket for 1.27mm pitch QFN package. The SG-MLF-7103 socket is designed for a 6.15mmx5.15mm package size and operates at bandwidths up to 30 GHz with less than 1dB of insertion loss (GSSG […]
Grypper sockets for UFS and eMMC devices are available from Ironwood Ironwood Electronics, continues to design and manufacture new Grypper test sockets for eMMC and UFS BGA devices. The Grypper sockets support the variety of sizes that 153 ball eMMC and UFS devices are produced, ranging from 7.5 x 7.5 mm to the 11.5 x […]
