QIP Receptacles (0.1″ pitch)-PART 1-16 · Ironwood

Receptacles

These 0.1″ pitch QIP receptacles are typically soldered to target board and QIP devices are plugged on to them. We offer them in several configurations including wire wrap version. Our QIP receptacles use gold plated pins for reliable connection throughout its life.

CATALOG

Categories: , , , , , Tags: , , , , , , , , , , , , , ,

Description

Receptacles

Receptacles provide pluggable interface for BGA, MGA, PGA, QIP, and QFP packages. We also offer parts that provide interconnects for in-circuit emulators. Ironwood offers the industry’s widest array of high quality receptacles. Our parts utilize gold plated pins and through-hole connectors exclusively.
These 0.1″ pitch QIP receptacles are typically soldered to target board and QIP devices are plugged on to them. We offer them in several configurations including wire wrap version. Our QIP receptacles use gold plated pins for reliable connection throughout its life.

 PART
NUMBER 		  RoHS   Top
Pin Count 		  Bottom
Pin Count 		  Top
Interface 		  Bottom
Interface 		  Tip To Tip
Outside in.		  Tip To Tip
Inside in.		  Socket
XY Size in.		  Part
Description
 SK-QIP34-01   Call*   34   34   QIP 34   QIP 34   0.6   0.4   0.9 x 0.7   Socket for QIP
 SK-QIP34-01W   Call*   34   34   QIP 34   QIP 34   0.6   0.4   0.9 x 0.7   Socket for QIP
 SK-QIP54-01   Call*   54   54   QIP 54   QIP 54   0.6   0.4   1.4 x 0.7   Socket for QIP
 SK-QIP54-01W   Call*   54   54   QIP 54   QIP 54   0.6   0.4   1.4 x 0.7   Socket for QIP
 SK-QIP64-01   Call*   64   64   QIP 64   QIP 64   0.75   0.925   1.65 x 1.03   Socket for QIP
 SK-QIP64-01W   Call*   64   64   QIP 64   QIP 64   0.75   0.925   1.65 x 1.03   Socket for QIP
 SK-QIP66-01   Call*   66   66   QIP 66   QIP 66   1.1   0.9   1.7 x 1.2   Socket for QIP
 SK-QIP66-01W   Call*   66   66   QIP 66   QIP 66   1.1   0.9   1.7 x 1.2   Socket for QIP
 SK-QIP68-01   Call*   68   68   QIP 68   QIP 68   1.4   1.2   1.75 x 1.5   Socket for QIP
 SK-QIP68-01W   Call*   68   68   QIP 68   QIP 68   1.4   1.2   1.75 x 1.5   Socket for QIP
 SK-QIP70-01   Call*   70   70   QIP 70   QIP 70   0.6   0.4   1.8 x 0.7   Socket for QIP
 SK-QIP70-01W   Call*   70   70   QIP 70   QIP 70   0.6   0.4   1.8 x 0.7   Socket for QIP
 SK-QIP78-01   Call*   78   78   QIP78   QIP78   1.65   1.45   2 x 1.75   Socket for QIP
 SK-QIP78-01W   Call*   78   78   QIP78   QIP78   1.65   1.45   2 x 1.75   Socket for QIP
 SK-QIP90-01   Call*   90   90   QIP 90   QIP 90   1.3   1.1   2.3 x 1.4   Socket for QIP
 SK-QIP90-01W   Call*   90   90   QIP 90   QIP 90   1.3   1.1   2.3 x 1.4   Socket for QIP
