Chip size socket connects LPDDR5 to system PCB with minimal signal loss. Supported device size is 14x14mm, 21×21 array, 0.65mm pitch BGA 441. Once the socket is soldered down to PCB, device can be simply plugged into it. This Grypper socket has excellent electrical performance of – 1dB insertion loss greater than 25.0 GHz. Force […]

Image Sensor Sockets: A Key Factor in Camera Design The proliferation of valuable high-resolution, high-speed, and 3D image sensors makes the use of sockets an increasingly important factor in camera development. Camera makers — and, therefore, image sensor makers — today are under greater pressure than ever to offer new models that provide higher resolution […]

JT21/22/32 CT Series HCMOS TCXOs Jauch Quartz’s JT21, JT22, and JT32 (2016, 2520, and 3225) CT series TCXOs are ideally suited to wireless applications Jauch Quartz’s JT21, JT22, and JT32 CT series Temperature-Compensated Crystal Oscillators (TCXOs) are ideally suited to wireless applications and various other applications in the telecommunications, industrial, and consumer sectors. Due to frequency […]

NEW PRECISION (VC)TCXOS: ULTRA-TIGHT FREQUENCY STABILITY OF ±50 PPB AND WIDE OPERATING TEMPERATURE RANGE A new range of Precision Temperature Compensated Crystal Oscillators (TCXOs) and the Voltage Controlled option (VCTCXO) will be launched by Jauch Quartz at electronica 2022. The new components impress with their tight frequency stability of ±50 parts per billion (ppb) and […]

The SM-BGA socket is constructed with high performance (> 40GHz bandwidth) and low inductance elastomer contactor. The temperature range is -55 °C to +150 °C. The pin self-inductance is 0.21 nH. Capacitance to ground is 0.15 pF. Current capacity is 4 amps per pin.

Overview Company Overview – Founded 1986 – 100,000 Sockets built – 1M+ adapters built – High Performance Adapters and Sockets – Many Custom Designs & Turn-Key Solutions – Engineering – Electrical and Mechanical – ISO9001:2015 Registration – Customers – Engineering and OEM Capabilities Overview – Simulation QFIN for heat sink design Microwave Studio for electrical […]

Socket your QFP172 using Extreme Temperature Socket with Superior Electrical Performance Ironwood Electronics recently introduced a new socket addressing high performance requirements for Burn-in and Test applications – SBT-QFE-3035. The contactor is a stamped spring pin with 14 gram actuation force per ball and cycle life of 125,000 insertions. The self inductance of the contactor […]

Socket your Flat No Lead package using elastomer socket with superior electrical performance Ironwood Electronics has recently introduced a new high performance elastomer socket for 1.27mm pitch QFN package. The SG-MLF-7103 socket is designed for a 6.15mmx5.15mm package size and operates at bandwidths up to 30 GHz with less than 1dB of insertion loss (GSSG […]
