MQ5 (UM-5) Quartz Crystal

– Pin Type Crystal, 7.7 x 3.1 mm
– high frequency stability
– wave soldering temperature: 260 °C max.
– package height 6.0 mm max.

• frequency range: 10.0 ~ 40.0 MHz (fund. AT-cut) / 30.0 ~ 105.0 MHz (3rd OT AT-cut) / 50.0 ~ 175.0 MHz (5th OT AT-cut) / 70.0 ~ 250.0 MHz (7th OT AT-cut)

Quartz Crystal · MQ5 (UM-5)
